Sun Pattern Architectural Glass Blocks
Glass Block Wall & Price Estimator
Send us this product’s SKU — THKXZ-17-SUN-WHT — with your quantity and country and we’ll reply with a full landed freight quote. Email us the SKU or add it to your Enquiry List and send the whole list in one go.
Questions about this product
Straight answers, no small print. Anything not covered — add it to your enquiry list and we will answer it in writing.
How heavy are glass blocks, and how many can I ship at once?
Each block is declared at 2.4 kg (actual weight 2.33 kg — we round up so a parcel never bills over). That puts a natural break on quantity:
• 9 blocks = 21.6 kg — still inside the 22 kg courier band
• 10 blocks = 24 kg — crosses into pallet freight
So if you are ordering for a small job, nine blocks is the sweet spot for courier delivery.
Do I need mortar, or silicone?
It depends on the wall. Traditional mortar beds suit load-bearing masonry walls; structural silicone suits panels, curves and situations where you want a cleaner line and more movement tolerance. Our glass block spacers hold a uniform 10 mm joint either way, and stop the blocks sinking or drifting while the bedding cures.
For anything structural or load-bearing, have the wall design signed off by a licensed builder or engineer — we supply the materials, not the structural certification.
Can I use them outdoors?
Glass block is used externally for screens, bathroom windows and light wells. What matters is the framing and the sealant detail, not the block. Ask us for the framing system that suits your opening before you build the wall.
How are they delivered?
Up to nine blocks go by courier. Ten and over travel on a pallet — palletised glass is the only way we will send a full wall's worth, because loose blocks in cartons break.
🚚 Direct Gold Coast Yard Pickup & Australia-Wide Pallet Freight: Bulk project packs and Trade pricing available. Compatible with standard 80mm mortar alignment spacers.
Architectural 190x190x80mm glass blocks featuring an embossed radial sunburst geometry. Channels natural sunlight into a vibrant focal point for front entry sidelights, garden feature walls, and internal pillars.
⚡ Architectural Performance
- Pattern Style: Sunburst Radial Crystal
- Privacy Rating: High Privacy with Radial Sunlight Accent
- Thermal & Acoustic: Sealed hollow cavity provides thermal barrier.
- Mortar System: 80mm mortar bed or silicone spacer grid.
📐 Coverage & Sizing Specs
- Block Dimensions: 190mm (H) x 190mm (W) x 80mm (Depth)
- Coverage Rate: Exactly 25 blocks per 1.0 m² (including 10mm mortar)
- Unit Weight: Approx. 2.2kg per block
- Applications: Showers, feature walls, windows & screening.
📐 Sun Pattern Architectural Glass Blocks Specifications
| Format Type | Hollow Architectural Glass Block (80mm Series) |
|---|---|
| Dimensions | 190mm x 190mm x 80mm |
| Coverage per m² | 25 Blocks = 1.0 m² (with 10mm mortar joint / spacers) |
| Privacy & Light Transmission | High Privacy with Radial Sunlight Accent |
| Internal Structure | Sealed partial-vacuum hollow core (high thermal & sound insulation) |
| Pickup & Delivery | Gold Coast Yard Pickup or Express Courier / Pallet Freight Australia-Wide |
